DÉTAILS
- Fabriqué aux États-Unis
- Chauffe jusqu'à 2,000 pieds carrés
- Jusqu'à 6-8 heures de combustion par remplissage (varie selon l'isolation du logement, les conditions environnementales et autres).
- Faibles taux d'émissions : pour une même quantité de chaleur, utilisez moins de combustible que les anciens poêles à bois
- Dimensions : 22"L x 30"H x 27"P
- Capacité de la chambre de combustion : 35 lb
- Taille du conduit d'évacuation : 6"
- Ventilateur : Inclus
MANUEL D'INSTALLATION ET D'UTILISATION
CARACTÉRISTIQUES
Fuel type | Dry cordwood (16" recommended) |
Recommended heating area | Up to 2,000 ft² |
Overall firebox volume | 2.45 ft³ |
EPA loading volume | 35 lb |
Maximum burn time | 6 - 8 h |
Maximum heat output-dry cordwood | 27,546 BTU/h (8.1 kW) |
Minimum overall heat output rate | 11,129 BTU/h (3.26 kW) |
Maximum overall heat output rate | 24,369 BTU/h (7.15 kW) |
Average overall efficiency-dry cordwood (HHV) | 74% |
Average overall efficiency-dry cordwood (LHV) | 80% |
Optimum efficiency | 80% |
Optimum heat transfer efficiency | 78% |
Average particulate emission rate | 1.96 g/h |
Average CO | 99.5 g/h |
Maximum log length | 18" |
Shipping weight | 390 lb |
Overall dimension (Width) | 24" |
Overall dimension (Height) | 30" |
Overall dimension (Depth) | 29" |
Warranty | 5 year limited |
Mobile home approved | Yes, US only |
Certified according to applicable standards | By an accredited laboratory (CAN/USA) |
Premium quality blower included (CFM) | 65 CFM included |
Combustion technology | Non catalytic |
Stainless-steel secondary-air system | Yes |
Flue outlet diameter | 6" |
Distance-center of the flue outlet to back unit | 8 3/4" |
Distance-center of the flue outlet to side unit | 11" |
Recommended chimney diameter | 6" |
Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
Minimum chimney height | 15' |
Door type | Single, glass with cast iron frame |
Door opening size (Width) | 18" |
Door opening size (Height) | 10 1/2" |
Glass type | Ceramic glass |
Glass surface - W x H | 16 3/4" x 12 3/4" |
Steel thickness-body | 3/16" |
Steel thickness-top | 1/4" |
Firebox size (Width) | 18" |
Firebox size (Height) | 12 3/4" |
Firebox size (Depth) | 22 5/8" |
Log positioning | Loading over width |
Firebox lined with refractory bricks | Yes |
Baffle type | Ceramic fiberboard (1/2") |
Canadian Standard (emissions) | CSA B415.1-10 |
Canadian Standard (safety) | ULC S627 |
USA Standard (safety) | UL 1482, UL 737 |
